Rubber shims Sound absorption and levelling.
-
3mm (3/32"), 5mm (3/16") or timber decking functionalities
ROTATE AND INSTALL FOR
EITHER 3mm (3/32") OR 5mm (3/16")
SPACER.REMOVE SPACER DISC AND SNAP OFF TOP 3mm/5mm SPACER AS INDICATED WITH A BLUE CIRCLE.
REINSTALL SIDEWAYS INTO LOCATING RIBS UNTIL SPACER DISC CLICKS IN PLACE AS INDICATED. SCREW TIMBER BEAMS SIDEWAYS THROUGH HOLES INDICATED WITH A BLUE CIRCLE.
-
Water Drainage System Prevents build up of water and other
waste material. -
Rapid Height Adjustment Dual twist-lock system for height extensions, with screw thread fo finer adjustment.
-
Locking Mechanism Locking pins fix the pedestals in place without the need for tools.
-
Slope-Correction - 0-5.5% angle adjustment. - ENSURE WINDOW IS IN UP-SLOPE POSITION AS SHOWN.
-
Wall Installation Cut for easy installation against walls and into corners.
